AXIAL FLOW FAN AS PER SPECIFICATION. FAN SHALL BE DIRECT DRIVEN. FAN AND CASING SHALL BE SUITAB;E FOR NORMAL MAKE UP AIR APPLICATION. MOTOR SHALL BE MOUNTED INSIDE THE FAN CASING & THERMALLY RATED. MOTOR SHALL BE SUITABLE FOR 415+-10% VOLTS, 50 CYCLE, 3 PHASE AC SUPPLY WITH HIGH EFFICIENCY, EFF-1 TYPE AND FAN TOTAL EFFICIENCY SHOULD NOT BE LESS THAN 65 %. THE FAN SHALL BE EQUIPPED WITH MOUNTING BRACKET, FIRE RATED FLEXIBLE CONNECTIONS, SPRING ISOLATORS FOR THE INSTALLATION OF THE FANS. 6000 CFM, 20 MM WC STATIC PRESSURE, MOTOR CAPACITY 2.2 KW
Description
AXIAL FLOW FAN AS PER SPECIFICATION. FAN SHALL BE DIRECT DRIVEN. FAN AND CASING SHALL BE SUITAB;E FOR NORMAL MAKE UP AIR APPLICATION. MOTOR SHALL BE MOUNTED INSIDE THE FAN CASING & THERMALLY RATED. MOTOR SHALL BE SUITABLE FOR 415+-10% VOLTS, 50 CYCLE, 3 PHASE AC SUPPLY WITH HIGH EFFICIENCY, EFF-1 TYPE AND FAN TOTAL EFFICIENCY SHOULD NOT BE LESS THAN 65 %. THE FAN SHALL BE EQUIPPED WITH MOUNTING BRACKET, FIRE RATED FLEXIBLE CONNECTIONS, SPRING ISOLATORS FOR THE INSTALLATION OF THE FANS. 6000 CFM, 20 MM WC STATIC PRESSURE, MOTOR CAPACITY 2.2 KW
