GLAND PACKING 12MM (STYLE - 1100) (MAKE - CHAMPION)
Description
GLAND PACKING 12MM (STYLE - 1100) (MAKE - CHAMPION)
GLAND PACKING 12MM (STYLE - 1100) (MAKE - CHAMPION)
CPVC PAD TYPE DOUBLE SKIN AIR WASHER UNIT(TYPE - DS-AWU-BC, CFM-15000, SP-70MMWG, BLOWER SIZE-BC-710 X 1, MOTOR(HP)-10.0, FAN SPEED RPM-1049, FAN EFF-81%, MOTOR-6.500BKW, SPL-77, FAN-8.78, PAD-30.0, PAD-200) , OUTER SKIN - 0.6MM THICK PRE-COATED SHEET, INNER SKIN - 0.6MM THICK PLAIN GI SHEET , INNER SKIN (WET SECTION) - GI SHEET, FRAME WORK - EXTRUDED ALUMINUM PROFILE, PANEL THICKNESS - (25±2)MM THICK , INSULATION OF PANELS - PUF (INJECTED) INSULATION (CFC/HFC FREE & FIRE RETARDANT)., WET SECTION - 18G SS-304 STAINLESS STEEL WATER STORAGE TANK. TANK CONSISTING OF 200MM THICK CELLULOSE PAD (AMCOOL/DRI APPROX. 88-89% ), CPVC WATER DISTRIBUTION ARRANGEMENT, CPVC PIPING (BETWEEN PUMP SUCTION AND DISTRIBUTION PIPE ONLY), SOCKET CONNECTION (FOR MAKEUP, QUICK FILL, OVERFLOW, DRAIN AND SUCTION) & SINGLE PHASE / SINGLE WATER CIRCULATING PUMP., BLOWER (BELT DRIVEN) - DIDW BACKWARD CURVED BLOWER MAKE ‘WOLTER’ , BLOWER & MOTOR MOUNTING - FOR FLOOR MOUNTED: BLOWER AND MOTOR ARE MOUNTED ON COMMON EXTRUDED ALUMINUM /GI CHANNEL BASE FRAME WITH RUBBER MOUNT VIBRATION ISOLATORS AND CONNECTED TO THE CASING WITH FIRE RETARDANT CANVAS CONNECTION. INSPECTION DOOR ARE EQUIPPED WITH LIMIT SWITCH, MARINE LIGHT & SAFETY GUARD, MOTOR (BELT DRIVEN/PLUG FAN) - TEFC (IE-02 REF. STD. IS:12615-2011) MOTOR MAKES ABB / BBL / CROMPTON / SIEMENS (BELT DRIVEN FAN WITH DRIVE PACKAGE AND V-BELTS) , PRE FILTERS - 50MM THICK ALUMINUM WIRE MESH FILTERS WITH GI FRAME
CPVC BRASS ADAPTOR 1/4" FLARE X 1/4" FLARE
CPVC CANCO BOLT FASTNER M10
CPVC SUNMICA 83825 GL LAMINATE
CPVC HOLE SAW CUTTER 16MM
CPVC 25 MM THICK DOUBLE SKIN CONSTRUCTION DRAW THRU TYPE FAN SECTION AIR HANDLING UNIT AS PER SPECIFICATION, EACH COMPLETE WITH FOLLOWING- SUPPLY AIR CENTRIFUGAL BACKWARD FAN WITH EFFICIENCY >= 60 %, TECF MOTORS SUITABLE FOR 415+-10% VOLTS, 50HZ, AC SUPPLY MEETING CRITERION AS PER ASHRAE STANDARD 90.1-2013 AND HIGH EFFICIENCY (EEF-1). VIBRATION ISOLATOR AND PRE -FILTURE (MERV-8) SHALL BE PROVIDED, FAN OUTLET VELICITY NOT EXCEEDING 10 MPS. 4000 CFM, 15 MM WC STATIC PRESSURE, MOTOR CAPACITY 1.5 KW
CPVC WIRE CUTTER
CPVC DOUBLE STEP STOOL (FG06)
CPVC HT NUT BOLT 12MM X 50MM FULL THREAD WITH WASHER
CPVC PIPE 32MM DIA
